Parcelcube™ 900
Static dimensioning/cubing system for parcel shipping and warehouse management.
How does it work?
- Simply place the product or shipment on the scale.
- Press a button or read a barcode and ParcelCube will capture the dimensions and weight of the box.
- Data is captured in less than one second – accurately and efficiently!
The SN-1 model includes a measuring, weighing scale with accurate and reliable four load cell construction, weight display for actual weight, barcode scanner (optional) and a calibration cube
(20 x 20 x 20 cm).
ParcelCube – the solution for both inbound and outbound logistics
| Physical |
| Dimensions, LxWxH 68 x 68 x 113 cm / 27 x 27 x 45 in Weight 15.6 kg / 34.4 lbs |
| Measuring capacity |
| Minimum 4 x 4 x 2 cm / 1.5 x 1.5 x 0.8 in Maximum 62 x 62 x 94 cm / 24 x 24 x 37 in Dimensional increment 0,1 cm / 0,3 cm / 1,0cm / 0,04 in / 0,12 in / 0,4 in |
| Weighing capacity |
| Minimum 0.05 kg / 0.11 lbs Maximum 55 kg / 120 lbs Increment 0.005 kg / 0.011 lbs |
| Other |
| Power Supply 100–240 VAC Measuring sensor Ultrasonic Weigh sensor 4 x load cell Weigh indicator RS232 Data output CSV / XML / HTTP User interface Windows PC connection RS232 / USB Operating temperature +10 … +30 °C |
| Accessories |
| Panel PC’s barcode reader Label printer |
| Custom software |
| Camera + camera interface |
